DVOR

MOPIENS’ Doppler VHF Omni-directional Radio Range (DVOR) is fully compliant with ICAO Annex 10 requirements. It under commercial operation at most of the domestic airports in Korea including Seoul AB (Code-1) Airport, Gimpo International Airport, Jeju International Airport, Cheongju International Airport, etc. This system has been supplied and is in operation worldwide including Thailand, Laos, Bhutan, Indonesia, Bangladesh, Turkey, Iran, Saudi Arabia, Mauritius. Malawi, Nigeria, etc.

page1-10_페이지_03
Key Features
  • Meets ICAO Annex 10 Requirements
  • Dual transponder, dual monitor and dual power supply in a single cabinet to provide easy maintenance and spacious room for operator
  • Provide non-stop operation of the power supply with redundant power system design
  • Compact and simplified modular design and ease of cabling for convenient maintenance
  • Air-cooled design
  • Hot-Swappable modules which are equipped with ejectors, enable the system to remain under operation while a module is being replaced MS Windows-based intuitive Graphical User Interface (GUI) provides detailed system information and easy maintenance
  • The software provides status of every antenna without the need to check antenna physically in case of failure of one or more antenna
  • The system can also be operated and controlled by rack mounted CSP (Control Status Panel) without the need of separate PC
  • Facility to check temperature and FAN functionality of the system through software to prevent malfunction of the system because of high temperature
  • Environment (door, temperature, fire) of shelter where the system is installed can be checked from remote location using software
  • Various functions, but not limited to, such as Changeover, Monitor Bypass, Transmitter Setting, Calibration of Monitor and Transmitter can be controlled by operation program
  • Provides log-in security features from Level 1 to Level 3
  • Supports wide-range of communication links (Built-in Modem, RS-485, RS-232, etc.)
  • Easy collocation with other NAVAID System such as DME, TACAN, etc
